Large 4-20mA Loop Powered LCD Meter - DPM 942

Product Description
$200.20
Maximum quantity available reached.
Sku: DPM 942
Out of stock, you can still order, item will leave our store in the next 2-3 weeks.

This large loop powered indicator features a 3½ digit LCD with 19mm (0.75") digit height. Calibration is by two multi-turn potentiometers and connection to the current loop is via two screw terminals.

Specifications:

- Accuracy (overall error): 0.05 0.1 % (±1 count)
- Operating temperature: 0 to 50 °C (32 to 122 °F)
- Sample rate: 3 samples/sec
- Loop Volt Drop: 3.9 to 4.8 V d.c.
- Supply Current: 4-20 mA

Applications:

- Precision Instrumentation Systems
- 4-20mA Loop Monitoring
- Panel-Mount Indication
- Low Power Voltage Measurement
- Process Control & Automation
